Overview
HP Z6 G5 A Workstation
1. | Integrated Front Handle | 2. | Power Button |
3. | HDD Activity Light | 4. | CTIA Headset Jack |
5. | Front I/O Premium:1 USB 3.2 Gen2x2 Type-C, 2 USB 3.1 Gen1 Type-A. Front I/O Entry:4 USB 3.1 Gen1 Type-A |
6. | SD Card Reader |
7. | 1 External 5.25" bay |
1. | Choice of 775W, 1125W/1275W or 1450W, 90% Efficient Power Supplies |
2. | Rear Power Button |
3. | Universal Audio Jack | 4. | Flex I/O Module (optional) |
5. | 1xRJ-45 integrated LAN port (1 GbE DASH) | 6. | 6 SuperSpeed USB3.2 Gen1 Type-A 5 Gbps signaling rate |
7. | 2x10GbE LAN ports (optional) | 8. | Integrated Rear Handle |
Features
Maximized Cores. Astounding Graphics. Unbound Potential
Tear through virtual production, 3D rendering, AI, and machine learning with the Z6 G5 A. Its innovative system design, with a nextgen AMD Ryzen Threadripper PRO CPU, combines an astounding number of cores in a single CPU with up to 3 GPUs.
The Z6 G5 A is a powerhouse for virtual production, 3D rendering, AI and machine learning. Its innovative system design, with a nextgen AMD Ryzen Threadripper PRO CPU, combines an astounding number of cores in a single CPU with up to three GPUs.
Create and render at once on intensive projects.
Create, render, process—all at once
Tear through virtual production or 3D modeling. The system design packs up to 96 cores in a single workstation CPU so there’s
room for up to three high-end GPUs and eight memory channels. And, do it all with efficient performance per watt.
Expandable. Flexible. Whisper Quiet
Designed to pack all the power and components you need now with room to grow. Get maximum expandability with up to 6 PCIe
slots (up to gen 5) and 12 NVMe SSDs. Conquer intense projects without throttling on a device designed to run quiet and cool
Comprehensive Security. Trusted Reliability
Get peace of mind with a workstation that's built to endure. The Z6 G5 A undergoes 360K hours of rigorous testing, MIL-STD testing,
and is certified for pro apps. And with HP Wolf Security for Business, it's protected below, in, and above the OS
Part of the world's most sustainable PC portfolio
At HP, we care about the impact our products have on our people, communities, and the planet. That’s why this device contains 40%
recycled plastics and is EPEAT® Gold registered. Take pride knowing that you are helping protect our shared future
Specification
Operating Systems: | •Windows 11 Pro • Ubuntu 22.04 LTS • Linux Ready • Red Hat Enterprise Linux |
Processor family: | AMD Ryzen Threadripper PRO processor |
Available Processors: | •AMD Ryzen Threadripper Pro 7995WX • AMD Ryzen Threadripper Pro 7985WX • AMD Ryzen Threadripper Pro 7975WX • AMD Ryzen Threadripper Pro 7965WX • AMD Ryzen Threadripper Pro 7955WX • AMD Ryzen Threadripper Pro 7945WX |
Form factor: | Tower |
Maximum memory: | 1 TB DDR5-5600 ECC SDRAM Transfer rates up to 5200 MT/s. |
Internal storage: | •1 TB up to 12 TB 7200 rpm SATA Enterprise HDD • 512 GB up to 4 TB HP Z Turbo Drive NVMe M.2 SSD • 512 GB up to 4 TB HP Z Turbo Drive PCIe SSD M.2 • 512 GB up to 4 TB HP Z Turbo Drive PCIe SED Opal 2 M.2 SSD • 512 GB up to 4 TB HP Z Turbo Drive Dual Pro PCIe SSD • 512 GB up to 4 TB HP Z Turbo Drive Quad Pro PCIe SSD |
Optical drive: | HP Slim DVD-ROM; HP Slim Blu-ray Writer; HP Slim DVD-Writer |
Available Graphics: | Ultra-High-End •NVIDIA RTX 6000 Ada Generation (48 GB GDDR6 dedicated) • AMD Radeon Pro W7900 (48 GB GDDR6 dedicated) • NVIDIA RTX 5000 Ada Generation (32 GB GDDR6 dedicated) • NVIDIA A800 (40 GB GDDR6 dedicated) High-End: • NVIDIA RTX 4500 Ada Generation (24 GB GDDR6 dedicated) • NVIDIA RTX A4500 (20 GB GDDR6 dedicated) • NVIDIA RTX 4000 Ada Generation (20 GB GDDR6 dedicated) • NVIDIA RTX A4000 (16 GB GDDR6 dedicated) • NVIDIA RTX 2000 Ada Generation (16 GB GDDR6 dedicated) • NVIDIA RTX A2000 (12 GB GDDR6 dedicated) • AMD Radeon Pro W7500 (8 GB GDDR6 dedicated) • AMD Radeon Pro W7600 (8 GB GDDR6 dedicated) Mid-Range: • NVIDIA T1000 (8 GB GDDR6 dedicated) • NVIDIA RTX A1000 (8 GB GDDR6 dedicated) Entry: • NVIDIA T400 (4 GB GDDR6 dedicated) • AMD Radeon RX 6400 (4 GB GDDR6 dedicated) • NVIDIA RTX A400 (4 GB GDDR6 dedicated) |
Audio: | Realtek ALC3205-CG |
Expansion slots: | 4 PCIe 5 x16; 2 PCIe 5 x4; 1 PCIe 4 x16; 3 PCIe 4 x4 (Rear bulkhead access can be achieved through all slots, but 2 PCIe 5 x4 and 2 PCIe 4 x4 are internal access only for M.2.) |
Memory card device: | 1 SD card reader (optional) |
Ports and connectors: | Front: 4 USB Type-A 5Gbps signaling rate (1 charging); 1 headphone/microphone combo ; Rear: 1 audio-in/out; 6 USB Type-A 5Gbps signaling rate; 1 RJ-45 (1 GbE) ; Optional Ports: 2 Thunderbolt 4 with USB Type-C 40Gbps signaling rate (USB Power Delivery, DisplayPort 1.4); Flex IO – choose one of the following options: 2 USB Type-A 5Gbps signaling rate, 1 USB Type-C 10Gbps signaling rate, 1 serial, 1 HP 1 GbE LC fiber NIC, 1 HP 10 GBase-T NIC, 1 HP 1 GbE single-port NIC, 1 HP 2.5 GbE NIC; Front Premium Version: 1 USB Type-C 20Gbps signaling rate, 2 USB Type-A 5Gbps signaling rate, 1 headphone/microphone combo |
Keyboard: | HP 125 Wired Keyboard; HP USB 320K Keyboard; HP USB Business Slim Wired SmartCard CCID Keyboard |
Mouse: | HP Wired Desktop 128 Laser Mouse; HP Wired 320M Mouse |
Drive Bays: | External: Four NVMe M.2 SSD; One 9.5 mm ODD; Internal: Two 3.5" HDD; Four PCIe M.2 SSD |
Security management: | Full volume encryption; HP Secure Erase; Kensington lock slot; Secure authentication; TPM 2.0 certified; HP BIOSphere; HP Sure Run; HP Sure Click; HP Sure Sense; HP Sure Admin; HP Platform Certificate; HP Sure Start; HP Sure Recover; Self-Encrypted Drives |
Security Software Licenses: | HP Wolf Pro Security Edition |
Management features: | HP Driver Packs; HP System Software Manager (download); HP BIOS Configuration Utility (download); HP Smart Support |
Power: | 1450 W internal power supply, up to 90% efficiency, active PFC; 1125 W internal power supply, up to 90% efficiency, active PFC; 775 W internal power supply, up to 90% efficiency, active PFC; 1275 W internal power supply, up to 90% efficiency, active PFC |
Dimensions: | 6.65 x 18.3 x 17.5 in; 16.9 x 46.5 x 44.5 cm |
Weight: | Starting at 29.1 lb; Starting at 13.2 kg; (Exact weight depends on configuration.) |
Energy star certified: | ENERGY STAR certified |
